Interface de audio thunderbolt

The Discrete 4 Pro SC is a direct descendant of the Antelope Audio Discrete range. It retains its strengths but inherits the latest generation of AN/NA converters and enhanced software features. With ultra-fast Thunderbolt 3 and universal USB 2.0, extremely low latency and enhanced effects processing capabilities, this audio interface meets the needs of both desktop and recording studio setups.

High-fidelity conversion for detailed sound in recording and playback based on 64-bit AFC™ clock technology provides a spacious stereo image with extreme separation of each instrument.
- Four console-quality mic preamps featuring six transistors on XLR jack combos for professional recordings. Inputs are mic and line compatible and two of them accept high impedance instruments.
- Four DC-coupled analogue outputs on TRS connectors, four independent headphone outputs, ADAT & S/PDIF I/O. All inputs/outputs can be used simultaneously in real time.
- 37 analogue modelled Synergy Core effects included and over 60 more available as options. Real-time processing with imperceptible latency.
- Two routing options - standard routing that lets you choose the audio source for each channel via a drop-down menu and virtual patching that allows for sophisticated drag-and-drop input/output configurations.

Translated with www.DeepL.com/Translator (free version)

Ficha técnica

DSP Sí

Analogue inputs
2 Mic / Line inputs
2 Mic / Line / Instrument inputs
Analogue Outputs
1 stereo output Monitor TRS Jacks, +20 dBu max
4 Line outputs on TRS, +20 dBu max
4 stereo headphone outputs
Mic preamps
EIN: -128 dBu (A-weighted)
Dynamic range: -122 dB (A-weighted)
THD: -116 dB
Max input level: +18 dBu
Max gain: 65 dB
Monitor D/A converter
Dynamic range: 130 dB
THD + N: -115 dB
A/D Converters
Dynamic range: 122 dB
THD + N: -116 dB
D/A converters (line outputs)
Dynamic range: 121 dB
THD + N: - 100dB
DC coupled
DIGITAL
Digital inputs
1 ADAT (up to 8 channels)
1 S/PDIF
Digital Outputs
1 ADAT (up to 8 channels)
1 S/PDIF
USB 2.0 I/O
USB 2.0 Type B connector
Thunderbolt connector 3 SUR USB-C
Clock
Word Clock outputs
2 x outputs @ 75 Ohms 3Vpp on BNC 32 - 192kHz
Clock system
Fourth generation Acoustically Focused Clocking 64-bit
Sampling frequencies (kHz)
32, 44.1, 48, 88.2, 96, 176.4, 192
OTHER
Operating temperature
0-50°C, 32-122°F
Weight (Approx)
1.7 kg/ 3.7 lbs
Dimensions (Approx)
Width: 261 mm / 10.2"
Height: 44 mm / 1.7"
Depth: 208 mm / 8.2"
Power Consumption
15 Watts
Translated with www.DeepL.com/Translator (free version)
